Flanges - 30

Flanges - 30

by Buckingham
$20.40 - $20.40
$20.40
$20.40 - $20.40
$20.40

Delivery time

Orders for 30R-F3 received by 12:00/Noon EST ship same business day. After 12:00/Noon EST ship next business day. Other variants ship in 7-14 business days.

SKU 30L-F1

The flange anchor attachment hole diameter has also been increased from 1 1/4" to 2" for easier connection of fall arrest/restraint devices.



A flange that features a new, lighter, more compact design.



30R-F2: For 7/8" Bolt (Available upon request)

30R-F4: For 1" Bolt (Available upon request)

30L-F2: For 7/8″ Bolt (Available upon request)

30L-F4: For 1″ Bolt (Available upon request)

Product Specifications:

Product Number: 30L / 30R
Product Name: Flange
Length: 5"
Width: 2.5"
Weight: 0.5 lbs.
Material: Steel
Coating: Hot Dip Galvanized
Anchor Attachment Hole Diameter: 2"
Rated Anchorage Point: 5,000 lbs.
Bolt Size: 5/8"-3/4"



Instructions & Warnings:
Flange Instructions

Brochures:
BuckBolts One Sheet PDF
